Description

LOA 90.3 m
Beam 23 m
Draft 7.8 m
Bollard Pull : 257 tons

Dynamic Positioning of class : DP 2
Free Deck area about 800m² with a deck strength of 10 metric tonnes per square meter
Capable of supplies of 1,100m³ Fuel Oils, 760m³ FW, 600m³ Liquid Mud and 364m³ Brine
Fire Fighting System installed
2 Cranes / Gears installed with a max lifting capacity of 15 tons

Built in year 2004
Design is : Maersk A-Type
Class : Russian Maritime Register
Flag : Russia
Gross Tonnage of 6,536 and Nett Tonnage of 1,960

Deadweight : 4,614 metric tonnes

Total passenger capacity 70 with 70 berths

Speed : 11 knots
Engines : 4 x MaK / Caterpillar Motoren 9M32, 17,280 kw, 600 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : Bowthruster + Sternthruster (1 Bow Thwart. CP thruster 1,500kw + 1 Bow Retract. dir. thruster 1,302kw + 2 Stern Thwart. CP thruster 883kw), Boilers : 1 x Hot Water Heater

Specifications

Engine(s)

4 x 17,280 kw, 600 rpm, MaK / Caterpillar Motoren 9M32,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
