Description

LOA 75 m
Beam 17.25 m
Draft 6.6 m

Built in year 2014
Design is : KCM 75M
Class : American Bureau of Shipping
Flag : Marshall Islands
Gross Tonnage of 2,955 and Nett Tonnage of 916

Dynamic Positioning of class : DP 2
Free Deck area about 700m² with a deck strength of 5.5 metric tonnes per square meter
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 7.5 tons
Deadweight : 3,255 metric tonnes

Total 48 berths

Speed : 12 knots
Engines : 2 x Niigata / Niigata Engineering Co Ltd 8L28HX, 4,412 kw, 750 rpm, Propellers 1 Z Type (Port Side) + 1 Z Type (Starboard)
Auxiliaries Engines : 3 Caterpillar 450 kw, Bowthruster + No Sternthruster (2 Bow Thwart. CP thruster 600kw)

Specifications

Engine(s)

2 x 4,412 kw, 750 rpm, Niigata / Niigata Engineering Co Ltd 8L28HX,
Propellers: 1 Z Type (Port Side) + 1 Z Type (Starboard)
